175036WT3X5810W60MV1 WEG AC Motor
175036WT3X5810W60MV1 – WEG AC Motor
W60 Hazardous Area 1750 HP 2P 6810/11 3Ph 2300/4000 V 60 Hz – – Foot-mounted
Downloads: 175036WT3X5810W60MV1
Additional information
| Weight | 10615 lbs |
|---|---|
| Manufacturer | WEG |
| Application | WPII |
| Frame Material | Cast Iron |
| Frame | 6810/11 |
| Degree of Protection | IP24 |
| Horsepower | 1750 HP |
| Kilowatts | 1320 kW |
| Phase | 3 Ph |
| Rated Voltage | 2300/4000 V |
| Rated Frequency | 60 Hz |
| Rated Current | 395/227 A |
| Rated Speed | 3575 RPM |
| Synchronous speed | 3600 RPM |
| Pole | 2:00 PM |
| Service Factor | 1.00 SF |
| Enclosure | |
| Mounting | Foot-mounted |
| Flange | Without |
| Rated Torque | 2570 ft.lb |
| Terminal Box | Left position |
| Ambient temperature | 0°C to +40°C |
| Altitude | 1000 m.a.s.l. |
| Noise level | 88.0 dB(A) |
| Misc |
