00336ES1E145T-S WEG AC Motor

00336ES1E145T-S WEG AC Motor - Image 2

00336ES1E145T-S WEG AC Motor

00336ES1E145T-S – WEG AC Motor

Rolled Steel 3 HP 2P 182/4T 1Ph 208-230 V 60 Hz IC01 – ODP – Foot-mounted
Downloads: 00336ES1E145T-S

SKU: 00336ES1E145T-S Category: WEG Electric Corp - AC Motors - 1 Phase & 3 Phase

Description
Additional information

Description

00336ES1E145T-S – WEG AC Motor. The W01 motor is the perfect option for applications that require robustness, low weight and high performance in a single product. The W01 Rolled Steel platform has good thermal performance and easy installation and maintenance. With steel plate frame and aluminum flange, these versatile motors provide torque and durability for the severest applications.

Downloads: 00336ES1E145T-S

Additional information

Weight	22.3 lbs
Manufacturer	WEG
Application	General Purpose
Frame Material	Rolled Steel
Frame	143/5T
Degree of Protection	IP55
Horsepower	3 HP
Kilowatts	2.2 kW
Phase	1 Ph
Rated Voltage	208-230/460 V
Rated Frequency	60 Hz
Rated Current	14.0-12.7/6.35 A
Rated Speed	3490 RPM
Synchronous speed	3600 RPM
Pole	2:00 PM
Service Factor	1.15 (1.00 @ 208V) SF
Enclosure	IC411 – TEFC
Mounting	Foot-mounted
Flange	Without
Rated Torque
Terminal Box	Left position
Ambient temperature	-20°C to +40°C
Altitude	1000 m.a.s.l.
Noise level	68.0 dB(A)
