00236OS3E56CFL-S WEG AC Motor

00236OS3E56CFL-S WEG AC Motor - Image 2

00236OS3E56CFL-S WEG AC Motor

00236OS3E56CFL-S – WEG AC Motor

W22 10 HP 2P 213/5TC 1Ph 208-230/460 V 60 Hz IC411 – TEFC – Foot-mounted
Downloads: 00236OS3E56CFL-S

SKU: 00236OS3E56CFL-S Category: WEG Electric Corp - AC Motors - Previous Generation

Description
Additional information

Description

00236OS3E56CFL-S – WEG AC Motor. The W01 motor is the perfect option for applications that require robustness, low weight and high performance in a single product. The W01 Rolled Steel platform has good thermal performance and easy installation and maintenance. With steel plate frame and aluminum flange, these versatile motors provide torque and durability for the severest applications.

Downloads: 00236OS3E56CFL-S

Additional information

Weight	25.7 lbs
Manufacturer	WEG
Application	General Purpose
Frame Material	Rolled Steel
Frame	56C
Degree of Protection
Horsepower	2 HP
Kilowatts	1.5 kW
Phase	3 Ph
Rated Voltage	230/460//190-220/380-415 V
Rated Frequency	60//50 Hz
Rated Current	5.64/2.82 A
Rated Speed	3470 RPM
Synchronous speed	3600 RPM
Pole	2:00 PM
Service Factor	1.15 (1.00 @ 208V) SF
Enclosure	IC01 – ODP
Mounting	Footless
Flange	C
Rated Torque	3.03 ft.lb
Terminal Box	Without Terminal Box
Ambient temperature	-20°C to +40°C
Altitude	1000 m.a.s.l.
Noise level	62.0 dB(A)
Misc	Replaced by : 00236OT3E56CFL-S – 12812242
