02036OT3E254JMV WEG AC Motor
02036OT3E254JMV – WEG AC Motor
Close Coupled Pump NEMA Premium Efficiency 20 HP 2P 254JM 3Ph 230/460 V 60 Hz IC01 – ODP – Footless
Downloads: 02036OT3E254JMV
Additional information
| Weight | 201 lbs |
|---|---|
| Manufacturer | WEG |
| Application | Close Coupled JM/JP |
| Frame Material | Cast Iron |
| Frame | 254JM |
| Degree of Protection | IP23 |
| Horsepower | 20 HP |
| Kilowatts | 15 kW |
| Phase | 3 Ph |
| Rated Voltage | 230/460 V |
| Rated Frequency | 60 Hz |
| Rated Current | 49.2/24.6 A |
| Rated Speed | 3520 RPM |
| Synchronous speed | 3600 RPM |
| Pole | 2:00 PM |
| Service Factor | 1.15 SF |
| Enclosure | IC01 – ODP |
| Mounting | W-6 |
| Flange | C |
| Rated Torque | 29.8 ft.lb |
| Terminal Box | Left position |
| Ambient temperature | -20°C to +40°C |
| Altitude | 1000 m.a.s.l. |
| Noise level | 66 dB(A) |
| Misc | Replaced by : 02036OT3E254JMV-S – 13482985 |
