E0.7512ET3WAXL90SF3W WEG AC Motor
E0.7512ET3WAXL90SF3W – WEG AC Motor
W22Xec IE3 0.75 kW 6P L90S 3Ph 220-230-240/380-400-415//460 V 50 Hz IC411 – TEFC – B3T
Downloads: E0.7512ET3WAXL90SF3W
Additional information
| Weight | 54.4 lbs |
|---|---|
| Manufacturer | WEG |
| Application | Hazardous Area IEC |
| Frame Material | Cast Iron |
| Frame | L90S |
| Degree of Protection | IP55 |
| Horsepower | 1 HP |
| Kilowatts | |
| Phase | 3 Ph |
| Rated Voltage | 220-230-240/380-400-415//460 V |
| Rated Frequency | 50 Hz |
| Rated Current | 3.36/1.93 A |
| Rated Speed | 950 RPM |
| Synchronous speed | 1000 RPM |
| Pole | 6:00 PM |
| Service Factor | 1.00 SF |
| Enclosure | IC411 – TEFC |
| Mounting | Foot-mounted |
| Flange | Without |
| Rated Torque | 5.56 ft.lb |
| Terminal Box | Top |
| Ambient temperature | -20°C to +40°C |
| Altitude | 1000 m.a.s.l. |
| Noise level | 45.0 dB(A) |
| Misc |
