02536OT3V256JPV – WEG AC Motor

Close Coupled Pump NEMA Premium Efficiency 25 HP 2P 256JP 3Ph 200/400 V 60 Hz IC01 – ODP – Footless
Downloads: 02536OT3V256JPV

SKU: 02536OT3V256JPV Category: WEG Electric Corp - AC Motors - Previous Generation

Description
Additional information

Description

02536OT3V256JPV – WEG AC Motor. W40 is a platform of Open Drip Proof motors (ODP) designed for industrial application in order to have a compact and light solution for the customer. The platform was designed to meet the market requirements of optimized and rugged motors, complying with international standard dimensions, safety and performance requirements.

Downloads: 02536OT3V256JPV

Additional information

Weight	243 lbs
Manufacturer	WEG
Application	Close Coupled JM/JP
Frame Material	Cast Iron
Frame	256JP
Degree of Protection	IP23
Horsepower	25 HP
Kilowatts	18.5 kW
Phase	3 Ph
Rated Voltage	200/400 V
Rated Frequency	60 Hz
Rated Current	68.5/34.3 A
Rated Speed	3530 RPM
Synchronous speed	3600 RPM
Pole	2:00 PM
Service Factor	1.15 SF
Enclosure	IC01 – ODP
Mounting	W-6
Flange	C
Rated Torque	37.2 ft.lb
Terminal Box	Left position
Ambient temperature	-20°C to +40°C
Altitude	1000 m.a.s.l.
Noise level	67 dB(A)
Misc	Replaced by : 02536OT3V256JPV-S – 13483003
