00712OT3E254TC-W40 WEG AC Motor
00712OT3E254TC-W40 – WEG AC Motor
W40 NEMA Premium Efficiency 75 HP 2P 364/5TS 3Ph 200/400 V 60 Hz IC01 – ODP – Foot-mounted
Downloads: 00712OT3E254TC-W40
Additional information
| Weight | 221 lbs |
|---|---|
| Manufacturer | WEG |
| Application | General Purpose |
| Frame Material | Cast Iron |
| Frame | 254TC |
| Degree of Protection | IP23 |
| Horsepower | 7.5 HP |
| Kilowatts | 5.5 kW |
| Phase | 3 Ph |
| Rated Voltage | 230/460//380 V |
| Rated Frequency | 60//50 Hz |
| Rated Current | 19.7/9.85 A |
| Rated Speed | 1180 RPM |
| Synchronous speed | 1200 RPM |
| Pole | 6:00 PM |
| Service Factor | 1.25 SF |
| Enclosure | IC01 – ODP |
| Mounting | Foot-mounted |
| Flange | C |
| Rated Torque | 33.4 ft.lb |
| Terminal Box | Left position |
| Ambient temperature | -20°C to +40°C |
| Altitude | 1000 m.a.s.l. |
| Noise level | 59.0 dB(A) |
| Misc |
